MetaTrailer 2 flat L7900 W2550 455/40x22,5

Item number chassis: 134402 Steel 650 Brinell: Bed 5 mm Instrument opening: L 1460mm W 1230mm Depth 400mm Hooks for load securing - outside lining of the platform The platform has a structured surface that reduces the risk of slipping Tires 455/40x22,5 diameter 930mm. Frame height 960mm Axles: one-piece axel body 120x120, Flange width 2 000 mm Load: 10,5 ton at 62 km/h, laser aligned Coated according KTL-method, black Axle distance 1 305mm, Rim connection 280x335x10, domed nuts Hydraulic brakes on all drums. Size 410x120. According VVFS 2003:20 Automatically adjusted brake arms AGS. Maximum hydraulic pressure 110 bar Cover sheets stop dirt entering the brake drums Oil volume 5L/210 bars Hydraulic functions: 1 DA (suspension on drawbar) Lights according TSV LED 12-24V 7 pol. Prepared console for mounting different drawbars Colour Metsjö grey Chassis weight: 4 820 kg, Technical load: 24 000 kg, Technical payload 21 340 kg Total weight allowed 21 000 kg, Payload 18 340 kg Surface treatment: chemical degreasing, blasting SA 2,5 The body is puttied. Painting according ISO 12944 A3.09. Colour system: Epoxy primer 2 x 70 µm. Top coat: Polyurethane 1 x 60 µm overall layer 200µm. Corrosion category C4 L
